Matrix 840G Console
The Matrix 840G is designed to provide years of service under typical agricultural operating conditions. A
tight fi tting enclosure, combined with rubber covers for all connectors mean that typical dusty environments
will not cause operational problems. While occasional splashing of water will not damage the unit, the Matrix
840G is not designed for direct exposure to rain. Take care not to operate the Matrix in wet conditions.
Figure 1-2: Console Front & Back
Built In Lightbar
Power Button
Power Button
USB Port with Rubber Cover
USB Port with Rubber Cover
Standard RAM Bracket
Bright Touch Screen
Rubber Connector
Covers
GPS Antenna
Connection
Integrated RAM Mount
Speaker
Recessed Connectors
SYSTEM COMPONENTS
Matrix 570G Console
The Matrix 570G is designed to provide years of service under typical agricultural operating conditions. A
tight fi tting enclosure, combined with rubber covers for all connectors mean that typical dusty environments
will not cause operational problems. While occasional splashing of water will not damage the unit, the Matrix
570G is not designed for direct exposure to rain. Take care not to operate the Matrix in wet conditions.
Figure 1-1: Console Front & Back
Speed Signal Connection
Camera Connection
Power Connection
Built In Lightbar
Power Button
USB Port
with Rubber Cover
Standard RAM Bracket
Bright Touch Screen
Home Button
Zoom In/Out Buttons
Rubber Connector
Covers
GPS Antenna
Connection Integrated RAM Mount
Speaker
Speed Signal Connection
Camera Connection
Power Connection
