Form I-MAPS II, Page 8

4. Dimensions and Clearances (cont'd)

4.2 Dimensions - Models RECA, REDA

FIGURE 2B - General Arrangement and Dimensions (inches/mm) of Models RECA and

REDA

Dimensions are shown by Cabinet Size. For a cross-reference of cabinet size and model size, refer to

Appendix, page 58.

IMPORTANT NOTE: "C" Size Cabinets MUST be loaded and unloaded by the

lifting lugs. DO NOT attempt to move a "C" size cabinet system with a fork lift.

��

��

��

�

��

�

��

�

��

�

��

�

��

�

��

Dimensions - inches (±1/8")

Cabinet

Size

Illustration Codes

Outside Air Inlet Opening

72-5/16

42-5/16

46-1/2

39-1/2

43-7/8

76-5/16

26-3/4 w/o power exhaust;

44 with power exhaust

73-5/8

48-1/8

24 W x 20 H

87-5/16

57-5/16

61-1/2

54-1/2

43-7/8

76-5/16

73-5/8

48-1/8

36 W x 20 H

100-23/32

68-7/8

68-9/16

105-1/4

102-1/2

66-5/8

49-5/8 W x 25-5/8 H

Dimensions - mm (±3mm)

Cabinet

Size

Illustration Codes

Outside Air Inlet Opening

1837

1075

1181

1003

1114

1938

679 w/o power exhaust;

1118 with power exhaust

1870

1222

610 W x 508 H

2218

1456

1562

1384

1114

1938

1870

1222

914 W x 508 H

2558

1749

1742

1677

1575

2673

965

2604

1692

1260 W x 651 H
