Register Name: LCD12
Register Description: LCD Display Register 12
Register Address: M2[1Ch]
Register Name: LCD13
Register Description: LCD Display Register 13
Register Address: M2[1Dh]
Register Name: LCD14
Register Description: LCD Display Register 14
Register Address: M2[1Eh]
Register Name: LCD15
Register Description: LCD Display Register 15
Register Address: M2[1Fh]
Register Name: LCD16
Register Description: LCD Display Register 16
Register Address: M2[0Fh]
MAXQ Family User’s Guide:
MAXQ2000 Supplement
Bit # 7 6 5 4 3 2 1 0
Reset 0 0 0 0 0 0 0 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Bit # 7 6 5 4 3 2 1 0
Reset 0 0 0 0 0 0 0 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Bit # 7 6 5 4 3 2 1 0
Reset 0 0 0 0 0 0 0 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Bit # 7 6 5 4 3 2 1 0
Reset 0 0 0 0 0 0 0 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Bit # 7 6 5 4 3 2 1 0
Reset 0 0 0 0 0 0 0 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
