background image

ADDENDUM TO SECTION 12: HARDWARE MULTIPLIER

The MAXQ2000 provides a hardware multiplier module that provides the following features (detailed in the MAXQ Family User’s Guide).

• Completes a 16-bit x 16-bit multiply-accumulate or multiply-subtract operation in a single cycle

• Includes 48-bit accumulator

• Supports seven different multiplication operations:

Unsigned 16-bit multiply
Unsigned 16-bit multiply and accumulate
Unsigned 16-bit multiply and subtract
Signed 16-bit multiply
Signed 16-bit multiply and negate
Signed 16-bit multiply and accumulate
Signed 16-bit multiply and subtract

The associated registers for this module are listed below.

Multiplier Example: 16-Bit Unsigned Multiplication

move MCNT, #021h

; 0010 0001
; 0 - OF : overflow flag (read only)
; 0 - MCW : write result to MC registers
; 1 - CLD : clears MA/MB/MCx to zero
; 0 - SQU : square function disabled
; 0 - OPCS : start op after writing MA,MB
; 00 - MCNT : MC = MA * MB
; 1 – SUS : unsigned operation

move MA, #01234h

; load first operand

move MB, #00055h

; load second operand, operation starts

move A[2], MC2

; should be 0000h

move A[1], MC1

; should be 0006h

move A[0], MC0

; should be 0B44h

MAXQ Family User’s Guide:
MAXQ2000 Supplement

REGISTER

ADDRESS

FUNCTION

MCNT

M2[00h]

Multiplier Control Register. Controls operation and mode selection for the multiplier.

MA

M2[01h]

Multiplier Operand A Register. Input register for multiplier operations.

MB

M2[02h]

Multiplier Operand B Register. Input register for multiplier operations.

MC2

M2[03h]

Multiplier Accumulate Register 2. Contains bits 32 to 47 of the accumulator.

MC1

M2[04h]

Multiplier Accumulate Register 1. Contains bits 16 to 31 of the accumulator.

MC0

M2[05h]

Multiplier Accumulate Register 0. Contains bits 0 to 15 of the accumulator.

MC1R

M2[0Bh]

Multiplier Read Register 1. Contains bits 16 to 31 of the last multiplier operation result.

MC0R

M2[0Ch]

Multiplier Read Register 2. Contains bits 0 to 15 of the last multiplier operation result.

Table 19. Hardware Multiplier Control Registers
