EVCO S.p.A. EVF818 | Installer manual ver. 1.0 | Code 144F818E104
page 73 of 76
Digital outputs:
8 outputs (electromechanical relays):
- 1 x 30 A res. output @ 250 VAC SPST type (K1) for
compressor management
- 6 x 8 A res. outputs @ 250 VAC of which five SPST type for
managing defrosting (K2), the evaporator fan (K3), the
condenser fan (K4), cabinet light or UV light (K7), the pump
down valve or alarm output (K8) and one SPDT type for
management of the door heating elements (K5)
- 1 x 16 A res. output @ 250 VAC SPDT type (K6) for heating
management of the needle probe.
Type of actions and complementary
features:
1C.
Communication port:
2 ports:
- 1 TTL type serial port
- 1 RS-48 serial port with MODBUS communication protocol.
