EVCO S.p.A. EVF818 | Installer manual ver. 1.0 | Code 144F818E104
page 53 of 76
11 SIGNALS AND INDICATIONS
11.1 Signals
The following table illustrates the meaning of the signalling LEDS.
LED Meaning
Blast chilling LED.
If it is on:
- blast chilling will be in progress (or has been performed).
If flashing:
- a blast chilling and storage cycle will have been selected.
Deep freezing LED.
If it is on:
- a soft deep freezing cycle will be in progress (or has been performed).
If flashing:
- a soft deep freezing and storage cycle will have been selected.
HARD
hard blast chilling/deep freezing LED
If it is on:
- hard blast chilling or deep freezing will be in progress (or has been performed).
If flashing:
- a hard blast chilling and storage cycle or a deep freezing and storage cycle will have been
selected.
temperature-controlled blast chilling/temperature-controlled deep freezing LED.
If it is on:
- a temperature-controlled blast chilling and storage cycle or a temperature-controlled deep
freezing and storage cycle will have been performed.
- temperature-controlled blast chilling or deep freezing will be in progress.
If flashing:
- a temperature-controlled blast chilling and storage cycle or a temperature-controlled deep
freezing and storage cycle will have been selected.
- the verification test for the correct insertion of the needle probe will not have been completed
successfully
- needle probe heating will be in progress.
Time-controlled blast chilling/time-controlled deep freezing LED.
If it is on:
- a time-controlled blast chilling and storage cycle or a time-controlled deep freezing and storage
cycle will have been performed.
- time-controlled blast chilling or deep freezing will be in progress.
If flashing:
- a time-controlled blast chilling and storage cycle or a time-controlled deep freezing and storage
cycle will have been selected.
- setting the real date and time will be in progress.
