EVCO S.p.A. EVF818 | Installer manual ver. 1.0 | Code 144F818E104
page 7 of 76
1.2 Summary table of the main features and the models
available
The following table illustrates the main features of the device and the models available.
“ / “ indicates the feature can be set via a configuration parameter.
User interface (without cover) EVF818
340.0 x 84.0 mm (13.385 x 8.400 cm; L x H) •
custom 3 + 4 + 1 digit display (with function icon) •
number of keys (capacitive touch-key type) 10
Control module (without cover) EVF818
166.0 x 116.0 mm (6.535 x 11.598 cm; L x H) •
Connections EVF818
faston + fixed screw terminal board + removable screw
terminal board
•
Power supply EVF818
115... 230 VAC •
Analogue inputs EVF818
cabinet probe PTC/NTC
needle probe 1 PTC/NTC
needle probe 2 PTC/NTC
needle probe 3 PTC/NTC
evaporator probe PTC/NTC
condenser probe PTC/NTC
Digital inputs (for NO/NC contact) EVF818
door micro switch •
high pressure •
low pressure •
