EVCO S.p.A. EVDRIVE03 | User manual ver. 3.4 | Code 144EPDE344
page 6 of 70
1.2 Summarizing table of the main features and available
models
The following table shows the main features of the devices and the available models.
The character “ / “ means the feature can be set through a configuration parameter.
Version (according to the model)
built-in LCD •
blind • • •
User interface
71.0 x 128.0 mm (2.795 x 5.039 in;
L x H), 4 DIN modules
• • • •
128 x 64 pixel single colour (black with
rearlighting through white LEDs) LCD graphic
display
•
number of buttons 6
index of protection
IP20
IP40 the front
IP20
IP40 the front
IP20
IP40 the front
IP20
IP40 the front
Main connections
extractable screw terminal blocks • • • •
Power supply
24 VAC or 24... 37 VDC • • • •
Analog inputs
analog input 1 (suction temperature backup
probe / suction pressure backup probe)
NTC / Pt 1000
/ 0-20 mA /
4-20 mA /
0-5 V
NTC / Pt 1000
/ 0-20 mA /
4-20 mA /
0-5 V
NTC / Pt 1000
/ 0-20 mA /
4-20 mA /
0-5 V
NTC / Pt 1000
/ 0-20 mA /
4-20 mA /
0-5 V
analog input 2 (suction temperature backup
probe / suction pressure backup probe)
NTC / Pt 1000
/ 0-20 mA /
4-20 mA /
0-5 V
NTC / Pt 1000
/ 0-20 mA /
4-20 mA /
0-5 V
NTC / Pt 1000
/ 0-20 mA /
4-20 mA /
0-5 V
NTC / Pt 1000
/ 0-20 mA /
4-20 mA /
0-5 V
analog input 3 (suction temperature probe) NTC / Pt 1000 NTC / Pt 1000 NTC / Pt 1000 NTC / Pt 1000
