EVCO S.p.A. EVDRIVE03 | User manual ver. 3.4 | Code 144EPDE344
page 42 of 70
Piu2 0 2 - - - - 0 Manufact.
analog input AI2 function
0 = not
used
1 = suction temperature backup probe
2 = suction pressure backup probe
Pia2 1 30 - - - - 1 Manufact.
analog input AI2 probe type
1 = NTC
probe
6 = Pt 1000 probe
10 = 4-20 mA transducer (0.5 - 8 barA)
11 = 4-20 mA transducer (0 - 30 barA)
12 = 4-20 mA transducer (-1 - 8 barG)
13 = 4-20 mA transducer (-1 - 15 barG)
14 = 4-20 mA transducer (0 - 30 barG)
20 = 0-5 V (0 - 7 barG)
21 = 0-5 V (0 - 25 barG)
22 = 0-5 V (0 - 60 barG)
30 = scaling
Par. Min. Mas. Unità Default Menu
Probe settings: analog input AI2
scaling
P2Xty 0 2 - - - - 0 Manufact.
X type
0 = 0-20
mA
1 = 4-20 mA
2 = 0-5 V
P2XM P2Xm
0:20.00
1:20.00
2:5.00
- - - - 20.00 Manufact. X max value
P2Xm
0:0.00
1:4.00
2:0.00
P2XM - - - - 0.00 Manufact. X min value
P2Yty 0 1 - - - - 0 Manufact.
Y type
0 = barG
1 = barA
P2YM P2Ym 300.00 barG/barA 1.00 Manufact. Y max value
P2Ym
-
300.00
P2YM barG/barA 0.00 Manufact. Y min value
Par. Min. Mas. Unità Default Menu Probe settings: analog input AI3
Piu3 3 3 - - - - 3 Manufact.
analog input AI3 function
3 = suction temperature probe
