ACCESSORIES
10.1
Programming key EVKEY10
10.1.1 Introduction
EVKEY10 is a programming key.
Through the key it is possible to make the upload and the download of the application software parameters and / or of
the configuration ones.
The key can be used on condition that the devices are powered.
10.1.2 Description
The following drawing shows the aspect of the programming key EVKEY10.
The following table shows the meaning of the parts of the key.
Part
Meaning
1 telephone
connector
2 reserved
10.1.3 Size
Size is in mm (in).
10.1.4 Connection to the device
Operate as follows:
1.
Plug in the telephone connector of the key into the programming port of the device.
To copy the parameters from the device to the key and vice-versa look at chapter 7 “CONFIGURATION”.
