EVCO S.p.A. EVDRIVE03 | User manual ver. 3.4 | Code 144EPDE344
page 34 of 70
Pp04 -40.0 40.0 °C -40.0 User LOP temperature
Pp05 -40.0 40.0 °C 40.0 User MOP temperature
Pp13 1.0 100.0 K 40.0 User PID proportional band
Pp14 0 999 s 120 User PID integral time
Pp15 0 999 s 30 User PID derivative time
Pp20 1 255 s 5 Installer start-up delay
Pp21 0.00 100.00 % 50.00 Installer start-uo position
Par. Min. Mas. Unità Default Menu Common SH algorithm
Fast 1 100 - - - - 100 User fast action
PNHi 0.0 25.0 K 1.0 User neutral high threshold
Pcz PNHi 25.0 K 3.0 User constant proportional threshold
SHFi 0 255 100 ms 10 User SH filter time constant
FaTh -10.0 10.0 K -1.0 User fast action threshold
Par. Min. Mas. Unità Default Menu Protections and alarms
Pa01 0 1 - - - - 0 Installer
enable communication alarm
1 = yes
Pa02 5 120 s 30 Installer communication alarm delay
Pa10 0 1 - - - - 0 Installer
enable LoSH alarm
1 = yes
Pa11 0.0 25.0 K 0.5 Installer LoSH alarm hysteresis
Pa12 0 250 min 3 Installer LoSH alarm delay
Pa20 0 1 - - - - 0 Installer
enable HiSH alarm
1 = yes
Pa21 0.0 25.0 K 1.0 Installer HiSH alarm hysteresis
Pa22 0 250 min 3 Installer HiSH alarm delay
