EVCO S.p.A. EVDRIVE03 | User manual ver. 3.4 | Code 144EPDE344
page 17 of 70
5 USER INTERFACE
5.1 Preliminary information
EVDRIVE03 is available in built-in and blind version (according to the model).
The built-in versions can be programmed through the user interface, the blind ones must be used with a remote user
interface (for example Vgraph): both the versions can be programmed through the set-up software system
Parameters Manager or through the plants monitoring and supervision one RICS; look at chapter 7 “CONFIGURATION”.
Using the programming key EVKEY it is also possible to make the upload and the download of the configuration
parameters.
5.2 Keyboard (not available in the blind versions)
The following table shows the meaning of the keyboard.
Button Preset function
cancel, hereinafter also called “button ESC”
move to left, hereinafter also called “button LEFT”
increase, hereinafter also called “button UP”
decrease, hereinafter also called “button DOWN”
move to right, hereinafter also called “button RIGHT”
confirmation, hereinafter also called “button ENTER”
5.3 Signalling LEDs
The following table shows the meaning of the LEDs at the front of the device.
LED Meaning
ON
LED power supply
if it is lit, the device will be powered
if it is out, the device will not be powered
STEP 1
LED stepper output 1
if it is lit, the valve will be stopped and completely closed
if it flashes slowly, the valve will be stopped and completely open
if it flashes quickly, the valve will be moving
if it is out, the valve will be stopped and open in an intermediary position
