EVCO S.p.A.
EVDRIVE03 | User manual ver. 3.4 | Code 144EPDE344
page 33 of 70
7.7
List of configuration parameters
The following table shows a full list of configuration parameters.
Par.
Min.
Mas.
Unità
Default
Menu
Control mode choice
Pcty
0
6
- - - -
6
I
main control type
0 = none
1 = analog positioner on AI1 (0-20 mA)
2 = analog positioner on AI2 (4-20 mA)
3 = analog positioner on AI3 (0-5 V)
4 = analog positioner on AI4 (0-10 V)
5 = analog positioner on AI4
6 = SH
control
SetP
1
2
- - - -
1
U
SH parameters set selection
1 = parameters set n. 1
2 = parameters set n. 2
Par.
Min.
Mas.
Unità
Default
Menu
Parameters set n. 1
Pc01 3.0 25.0
K
6.0
User SH
setpoint
Pc02 1.0 3.0
K
2.0
User LoSH
setpoint
Pc03 10.0 40.0
K
15.0
User HiSH
setpoint
Pc04 -40.0 40.0
°C
-40.0
User LOP
temperature
Pc05 -40.0 40.0
°C
40.0
User MOP
temperature
Pc13
1.0
100.0
K
40.0
User
PID proportional band
Pc14
0
999 s 120 User
PID
integral
time
Pc15
0
999
s
30
User
PID derivative time
Pc20 1 255 s
5 Installer
start-up
delay
Pc21 0.00 100.00 %
50.00 Installer
start-uo
position
Par.
Min.
Mas.
Unità
Default
Menu
Parameters set n. 2
Pp01 3.0 25.0
K
6.0
User SH
setpoint
Pp02 1.0 3.0
K
2.0
User LoSH
setpoint
Pp03 10.0 40.0
K
15.0
User HiSH
setpoint
