EVCO S.p.A. EVDRIVE03 | User manual ver. 3.4 | Code 144EPDE344
page 39 of 70
Pr51 Pr50 9999 step 1596 Manufact. maximum regulation steps
Pr52 Pr51 9999 step 1600 Manufact. overdrive steps
Pr53 25 1000 step/s 200 Manufact. stepping rate
Pr54 0 1000 mA 120 Manufact. operating phase current
Pr55 0 1000 mA 0 Manufact. holding phase current
Par. Min. Mas. Unità Default Menu Valve and driver: debug
Prd0 25 1000 step/s 25 User debug step rate
Prd1 0.00 Prd2 % 0.00 User debug minimum position
Prd2 Prd1 100.00 % 100.00 User debug maximum position
Par. Min. Mas. Unità Default Menu Valve and driver: backup battery
Pb01 0 1 - - - - 0 Installer
backup battery
1 = present
Par. Min. Mas. Unità Default Menu
Valve and driver: digital I/O settings
and various
Ph01 0 8 - - - - 0 Manufact.
digital output DO1 function
0 = disabled
1 = any
alarm
2 = probe errors
3 = following low SH alarms
4 = following MOP alarms
5 = following
valve alarm
6 = used for solenoid valve
7 = alarms + used for solenoid valve
8 = valve resyncchronization signal is
necessary
Ph02 0 1 - - - - 0 Manufact.
relay logic
0 = normally
unexcited
1 = normally excited
Ph10 0 1 - - - - 0 Manufact.
free of voltage digital input DI1 logic
0 = normally
open
1 = normally closed
