VS-Link Messages 81
Windows NT
VS-Link responsive;
data traffic sent, but
nothing received since
last inquiry.
Similar to above, except the VS-Link device
has sent data successfully.
VS-Link active.
Normal state: the VS-Link device is installed
correctly and active with data traffic.
Poor connection to
VS-Link.
This message displays if retransmissions are
occur, frames arrive out of sequence, or more
than 2% of the total packets arrive out of
sequence. This generally indicates a cable,
connector, or LAN termination problem.
Counts reset.
This message displays immediately after you
click the Reset button.
Table 6. VS-Link Reported State Messages
Message Description
Invalid
An illegal VS-Link state has been detected.
Reset the VS-Link device.
Init
This is the normal state for undetected and
inactive VS-Link devices.
InitOwn
The server has acquired the VS-Link device
but has not downloaded the control software.
SendCode
The server has acquired the VS-Link device
and is in the process of downloading the
control software.
Connect
The server has completed the download and
is completing initialization.
Active
The normal state for a VS-Link device that is
attached to an NT server and is ready for
data traffic.
Not found
The specified MAC address is not configured
on this NT server.
Undefined
No VS-Link devices are configured on this
NT server.
Table 5. VS-Link Summary Messages (Continued)
Message Description
