9.2 Using the XE EDP Command
The XE EDP command can be used to remotely query
the CW-90/CW-90X for the error conditions shown on
the front panel. The XE command returns a 5-digit
number in the format:
xxxxx yyyyy
where xxxxx contains a decimal representation of any
existing error conditions as described in Table 9-2.
If more than one error condition exists, the number
returned is the sum of the values representing the error
conditions. For example, if the XE command returns
the number 1040, this value represents the sum of an A/
D reference error (1024) and an A/D calibration
checksum error (16).
XE Error
Code Description XEH Hex Value
1 VIRGERR 0x00000001
2 PARMCHKERR 0x00000002
4 LOADCHKERR 0x00000004
8 PRINTCHKERR 0x00000008
16 ENVRAMERR 0x00000010
32 ENVCRCERR 0x00000020
64 BATTERYERR 0x00000040
32768 GRAVERR 0x00008000
65536 ADPHYSICALERR 0x00010000
131072 TAREERR 0x00020000
262144 EACCOVER 0x00040000
524288 STRINGERR 0x00080000
1048576 RESERVED_PF 0x00100000
2097152 RTCERR 0x00200000
4194304 MISSINGHWERR 0x00400000
8388608 CFGCONFLICTERR 0x00800000
16777216 UNRECOVERABLEERR 0x01000000
0x10000 - 0x80000000 Reserved
Table 9-2. Error Codes Returned on XE Command
9.3 Status Messages
Two EDP commands, P and ZZ, can be used to provide
status about the indicator. These commands are
described in the following sections.
9.3.1 Using the P EDP Command
The P EDP command returns the current displayed
weight value to the EDP port, along with the units
identifier. If the indicator is in an underrange or
overload condition, the weight value is replaced with
^^^^^ (overload) or _ _ _ _ _ (underrange).
9.3.2 Using the ZZ EDP Command
The ZZ EDP command can be used to remotely query
which annunciators are currently displayed on the
indicator front panel. The ZZ command returns the
currently displayed weight and a decimal number
representing the LED annunciators currently lit. The
format of the returned data is:
wwwwww uu zzz
where wwwwww uu is the current displayed weight and
units, zzz is the annunciator status value (see Table 9-3).
If more than one annunciator is lit, the second number
returned is the sum of the values representing the active
annunciators.
Example: If the annunciator status value returned on
the ZZ command is 145, the gross, standstill, and lb
annunciators are lit. 145 represents the sum of the
values for the standstill annunciator (128), gross mode
annunciator (16), and the lb/primary units annunciator
(1).
Table 9-3. Status Codes Returned on the ZZ Command
Decimal
Value Annunciator
1 lb/primary units
2 kg/secondary units
4 Count
8 Tare entered
16 Gross
32 Net
64 Center of zero
128 Standstill
