Note
40 CW-90/90X Checkweigher
6. Press the UNDER key. The UNDER light begins flashing and the value with flashing digit is shown.
7. Using the and keys to increment/decrement the values and the and keys to move between digits,
enter the desired under value. If using the CW-90, you can also use the numeric keypad to enter the desired
under value.
To discard any changes and return to weigh mode, press the Menu button.

8. When the desired value is displayed, press Enter . The decimal point flashes.
9. To change the position of the decimal point, use the and keys until it is in the desired position.
10. Press Enter again to accept the value and return to weigh mode.
5.1.2 Value Set: Push
To set the over/under values using weight on the scale:
1. Place the weight you want to be determined as “over” on the scale.
2. Press the OVER key.
3. The weight is captured and set as the over value.

The display will read Stored and the over light flashes.
4. Place the weight you want to be determined as “under” on the scale.
5. Press the UNDER key.
6. The weight is captured and set as the under value.

The display will read Stored and the under light flashes.
7. The Accept band is set as the gap between the over and under settings. See Figure 5-2 for an example.
5.2 Target Weight Mode
In Target Weight mode, the over and under values can only be set by keying in the values. The VALSET parameter
only pertains to setting the target weight value. The Accept band is determined based on a desired target weight.
ACCEPT UNDER OVER
8.00 13.00
8.01-12.99
Under = 2.00
Over = 3.00
Target = 10.00
Figure 5-3. Example of Under/Over/Target Settings in Target Weight Mode.
5.2.1 Value Set: Keyed
1. Press the TARGET key. The Accept light begins flashing and a flashing digit is shown.
2. Using the and keys to increment/decrement the values and the and keys to move between digits,
enter the desired value. If using the CW-90, you can also use the numeric keypad to enter the desired target
weight value.
Note
Note
To discard any changes and return to weigh mode, press the Menu button.

3. When the desired value is displayed, press Enter .

The decimal point flashes.
4. To change the position of the decimal point, use the and keys until it is in the desired position.
5. Press Enter again to accept the value and return to weigh mode.
6. Press the OVER key. The Over light begins flashing and a flashing digit is shown.
7. Using the and keys to increment/decrement the values and the and keys to move between digits,
enter the desired value. If using the CW-90, you can also use the numeric keypad to enter the desired over
value.
To discard any changes and return to weigh mode, press the Menu button.

