Table 6-4. SCALES Serial Commands
Command Description Values
SC.GRADS Graduations 1–100000
SC.ZTRKBND Zero track band 0, 0–100
SC.ZRANGE Zero range 1.900000, 0–100
SC.MOTBAND Motion band 1, 0–100
SC.SSTIME Standstill time 1–65535
SC.OVRLOAD Overload FS+2%, FS+1D, FS+9D, FS
SC.DIGFLTR1
SC.DIGFLTR2
SC.DIGFLTR3 Digital filtering 1, 2, 4, 8, 16, 32, 64, 128, 256
SC.DFSENS Digital filter cutout sensitivity 2OUT, 4OUT, 8OUT, 16OUT, 32OUT, 64OUT, 128OUT
SC.DFTHRH Digital filter cutout threshold NONE, 2D, 5D, 10D, 20D, 50D, 100D, 200D, 250D
SC.THRESH Zero threshold 0–9999999
SC.SMPRAT Sample rate 30HZ, 60HZ, 120HZ, 240HZ, 480HZ, 960HZ
SC.PWRUPMD Power up mode GO, DELAY
SC.TAREFN Tare function BOTH, NOTARE, PBTARE, KEYED
SC.PRI.DECPNT Primary units decimal position 8.888888, 88.88888, 888.8888, 8888.888, 88888.88,
888888.8, 8888888, 8888880, 8888800
SC.PRI.DSPDIV Primary units display divisions 1D, 2D, 5D
SC.PRI.UNITS Primary units lb, kg, g, oz, lb/oz, CUSTOM, OFF
SC.PRI.CUNITS Primary custom units Specify units if SC.PRI.UNITS=CUSTOM
SC.ACCUM Accumulator enable ON, OFF
SC.VISIBLE Scale visibility ON, OFF
SC.WZERO Zero calibration —
SC.WVAL Test weight value test_weight_value
SC.WSPAN Span calibration —
SC.WLIN.F1–
SC.WLIN.F5 Actual raw count value for linearization
points 1–5 0–16777215
SC.WLIN.V1
SC.WLIN.V5 Test weight value for linearization points
1–5 0.000001–9999999
SC.WLIN.C1–
SC.WLIN.C5 Calibrate linearization points 1–5 —
SC.LC.CD Deadload coefficient —
SC.LC.CW Span coefficient —
SC.LC.CZ Temporary zero —
SC.REZERO Rezero —
SC.SEC Secondary units lb, kg, g, oz, lb/oz, CUSTOM, OFF
SC.TER Tertiary units lb, kg, g, oz, lb/oz, CUSTOM, OFF
50 CW-90/90X Checkweigher
Command Description Values
EDP.BAUD#p Port baud rate 1200, 2400, 4800, 9600, 19200, 28800, 38400, 57600, 115200
EDP.BITS#p Port data bits/parity 8NONE, 7EVEN, 7ODD
EDP.TERMIN#p Port termination character CR/LF, CR
Table 6-5. SERIAL Port Serial Commands
