30
CW-90/90X Checkweigher
SETUP Menu
Parameter
Choices
Description
Level 2 submenus
SCALE
Configure scale settings. See the level 3 submenus of Table 3-4 on page 19 for parameter
descriptions.
FEATUR
Set checkweighing options, region settings, view Unit ID, and set consecutive numbering.
See level 3 submenus of Table 3-5 on page 24 for parameter descriptions.
SERIAL
PORT 1
PORT 2
PORT 3 (Option Card)
Configure communications ports. See level 3 submenus below for parameter descriptions.
PFORMT
GFMT
NFMT
ACCFMT
STRM.FM
BUF.FMT
H1
H2
Sets the print format for gross weight, net weight, accumulated weight, stream, buffer,
Header 1 and Header 2.
DIG IO
DIO 1
DIO 2
DIO 3
DIO 4
Assign digital input/output functions.
VERS
SOFTWR
REG
DEFALT
Displays the software version.
Displays the regulatory version.
Restores settings to their default values.
Level 3 submenus
PORT 1
TRIGGE
PRNMSG
BAUD
BITS
STOP B
TERMIN
EOLDLY
ECHO
Specifies Port 1’s mechanism for triggering a transmission of data, print message, baud
rate, bits, stop bits, termination character, end-of-line delay, and echo.See level 4
submenu for parameter descriptions.
Note
If any port is set to PRNMSG=ON, PRINT will display.
PORT 2
TRIGGE
PRNMSG
BAUD
BITS
STOP B
TERMIN
EOLDLY
ECHO
Specifies Port 2’s mechanism for triggering a transmission of data, print message, baud
rate, bits, stop bits, termination character, end-of-line delay, and echo.See level 4
submenu for parameter descriptions.
Note
If any port is set to PRNMSG=ON, PRINT will display.
PORT 3
TRIGGE
PRNMSG
BAUD
BITS
STOP B
TERMIN
EOLDLY
ECHO
Specifies Port 3’s mechanism for triggering a transmission of data, print message, baud
rate, bits, stop bits, termination character, end-of-line delay, and echo.See level 4
submenu for parameter descriptions.
Note
If any port is set to PRNMSG=ON, PRINT will display.
SOFTWR
V 1.00
Displays the software version.
REG
LR,V.1.00
Displays the legally relevant version.
DEFALT
NO
YES
Resets settings to default values if YES is selected.
Table 3-7. Serial, PFORMT, DIG I/O, VERS Submenu Parameters
