Rice Lake Static Weighing User Manual
Page 17
Item No.
Part No.
Description (Quantity)
1
Enclosure
1
2
Mounting Plate, Display
1
3
14621
Nut, Kep 6-32NC HEX
2
4
85202
85203
Power Cord Assy, 120VAC
Power Cord Assy, 230VAC
1
5
68600
Cord Grip, PG11
1
6
68599
Seal Ring, Nylon PG11
1
7
68601
Nut, PG11
1
8
58983
Cable Grip, SL-7 w/Nut
3
9
16892
Label, Earth Ground
1
10
15134
Washer, Lock NO 8 Type A
3
11
14626
Nut, Kep 8-32NC HEX
3
12
45043
Wire, Ground 4in W/No. 8
1
13
104914
104915
Overlay, Membrane Switch (CW-90)
Overlay, Piezo (CW-90X)
1
14
105850
Bracket, Power Supply
1
15
76556
Power Supply, Switching
1
16
14822
Screw, Mach 4-40NC x 1/4
6
17
14825
Screw, Mach 4-40NC x 1/4
4
18
105976
Cable Assy, Power Supply
1
19
102354
CPU
1
19
105741
Display
1
20
69291
Battery, 3v Coin Lithium
1
21
42640
Screw, Mach 1/4-28NF X 1/4
1
22
44676
Washer, Bonded Sealing
1
23
Backplate
1
24
84388
Gasket, Backplate 420
1
25
88733
Vent, Breather Sealed
1
26
88734
Nut, Breather Vent
1
27
14862
Screw, MACH 8-32NCx3/8
4
28
45042
Washer, Bonded Sealing SST
4
29
29635
Stand, Tilt SST
1
30
103988
Washer, Nylon .52 ID
2
31
103610
Knob, Black 1/4-20
2
32
53307
Label
1
33
53308
Label
1
34
16861
Label, Warning High
1
--
105945
Parts Kit, CW-90/90X
1
--
107476
Bench Scale Foot
--
105555
Coupling Nut for Feet and Overload Stops
Installation
13
Figure 2-7. CW-90/CW-90X Replacement Parts
