32 CW-90/90X Checkweigher
BAUD 9600
19200
28800
38400
57600
115200
1200
2400
4800 Baud rate. Selects the transmission speed for the port.
BITS 8NONE
7EVEN
7ODD Selects number of data bits and parity of data transmitted from the port.
STOP B 1
2 Stop bits. Sets the number of stop bits to 1 or 2.
TERMIN CR/LF
CR Termination character. Selects termination character for data sent from the port.
EOLDLY 000000 End-of-line delay. Sets the delay period, in 0.1-second intervals, from when a formatted
line is terminated to the beginning of the next formatted serial output. Value specified must
be in the range 0-255, in tenths of a second (10 = 1 second).
Note
An EOL may be required for continuous transmission at slower baud
rates to ensure the receiving buffer is empty before another string is
transmitted
ECHO ON
OFF This command enables or disables echoing of the serial commands sent to the indicator.
PRNMSG ON
OFF This parameter enables or disables the print message being displayed momentarily when
the unit receives a Print command.
Level 5 submenus
FUNCTN OVER
UNDER
ACCEPT
ZEROBD Sets the output to function when a value in the over, under, accept, or zero band is
reached.
TIMER 000000 Set the timer to 0 for output to remain on until the function state changes. Enter a value (in
20-millisecond increments, maximum 65535) to turn the digital output off after the
specified time (even though the function state has not changed).
TRIP FRERUN
STABLE FRERUN allows the output to toggle in motion;
STABLE waits for standstill.
SETUP Menu
Parameter Choices Description
Table 3-7. Serial, PFORMT, DIG I/O, VERS Submenu Parameters (Continued)
