ACCEPT UNDER OVER
9.50 11.00
9.51-10.99
Under = 0.50 (.05%)
Over = 10.00 (10%)
Target = 10.00
42 CW-90/90X Checkweigher
Figure 5-4. Example of Under/Over/Target Settings in Target Weight Mode.
5.3.1 Value Set: Keyed
1. Press the TARGET key. The Accept light begins flashing and a flashing digit is shown.
2. Using the and keys to increment/decrement the values and the and keys to move between digits,
enter the desired value. If using the CW-90, you can also use the numeric keypad to enter the desired target
percent value.
Note
Note
Note
To discard any changes and return to weigh mode, press the Menu button.

3. When the desired value is displayed, press Enter .

The decimal point flashes.
4. To change the position of the decimal point, use the and keys until it is in the desired position.
5. Press Enter again to accept the value and return to weigh mode.
6. Press the OVER key. The Over light begins flashing and a flashing digit is shown.
7. Using the and keys to increment/decrement the values and the and keys to move between digits,
enter the desired value, in percent (entering 10 equals 10% ). If using the CW-90, you can also use the
numeric keypad to enter the desired over value.
To discard any changes and return to weigh mode, press the Menu button.

8. When the desired value is displayed, press Enter .

The decimal point flashes.
9. To change the position of the decimal point, use the and keys until it is in the desired position.
10. Press Enter again to accept the value and return to weigh mode.
11. Press the UNDER key. The Under light begins flashing and a flashing digit is shown.
12. Using the and keys to increment/decrement the values and the and keys to move between digits,
enter the desired value, in percent (entering 5 equals 5% ). If using the CW-90, you can also use the numeric
keypad to enter the desired under value.
To discard any changes and return to weigh mode, press the Menu button.

13. When the desired value is displayed, press Enter .

The decimal point flashes.
14. To change the position of the decimal point, use the and keys until it is in the desired position.
15. Press Enter again to accept the value and return to weigh mode.
5.3.2 Value Set: Push
1. Place the weight you want to be used as the “target percent” value on the scale.
2. Press the Enter key. The Accept light flashes and the indicator displays STORED . The weight has been
captured and stored as the target percent value.
3. Press the OVER key. The Over light begins flashing and a flashing digit is shown.
4. Using the and keys to increment/decrement the values and the and keys to move between digits,
enter the desired value, in percent (entering 10 equals 10% ). If using the CW-90, you can also use the
numeric keypad to enter the desired over value.
Note
To discard any changes and return to weigh mode, press the Menu button.

