Crestron DM-MD8X8 8x8 DigitalMedia™ Switcher
Input Rotate Rate
Input Rotation Rate
1 Second
2 Seconds
3 Seconds
• Turn the selection knob to highlight a rotate rate and press the ENTER
button. Rotate rates from one to 60 seconds can be selected. The current
selection is indicated with an asterisk (*).
• Press the MENU button to return to the list of options for the DMC-VID4.
Video Input Settings Each of the inputs on the DMC-VID4 can be configured and monitored. To
configure or monitor a video input:
• Turn the selection knob to highlight the video input to be configured or
monitored (Video Input 1 Settings through Video Input 4 Settings) and
press the ENTER button.
Video Settings
Video Settings
Name: Front Door
Video Type: No Video
Resolution: No Video
• Turn the selection knob to view information on video type, resolution,
frame rate and aspect ratio. The name of the selected video input and the
picture controls for the selected video input can also be adjusted.
Name:
The name of the video input can be set to provide a label for the image
when it is displayed. To change the name assigned to the video input:
¾ Turn the selection knob to highlight Name and press the ENTER
button.
¾ A cursor will appear next to the current name and controls for changing
the name will also be displayed. To cancel and return to the list of
options for the input card, press the MENU button.
Operations Guide – DOC. 6755A 8x8 DigitalMedia™ Switcher: DM-MD8X8
• 79
