Crestron DM-MD8X8

8x8 DigitalMedia™ Switcher

Show Full EDID

Show Full EDID
Preferred Resolution
Supported Resolutions
Audio Formats

• Turn the selection knob to highlight the data to be viewed and press the

ENTER button.

• Press the MENU button to return to list of available EDID data.
• Press the MENU button to return to the list of options for the input card.

Perform KSV Limit Test

The DMC-HD-DSP can analyze the connected source to determine the maximum
number of KSVs it can support. To perform a KSV Limit test:

• Turn the selection knob to highlight KSV Limit Test and press the ENTER

button.

KSV Limit Test

KSV Limit Test

Perform KSV Limit Test

on this input stream?

No

Yes

• Press the soft button labeled Yes to begin the test. To cancel and return to

the list of options for the input card, press the soft button labeled No.

If Yes is pressed, the DM-MD8X8 will poll the connected source to
determine the maximum number of KSVs it can support. The test results are
displayed when the test is complete.

Operations Guide – DOC. 6755A

8x8 DigitalMedia™ Switcher: DM-MD8X8

75
