signal. Available information includes format, frequency, and channels. To view
audio settings:
• Turn the selection knob to highlight Audio Settings and press the ENTER
ttings
button.
Audio Se
Audio
Format: PCM
Frequency: 480kHz
Channels: 2
• Press the MENU button to return to the list of options f the input card.
or
Loopback Settings The
UT
e
DMC-HD-DSP can display information about the device connected to the
HDMI OUT port as well as information about the signal passed to the HDMI O
port on the DMC-HD-DSP. Available information includes HDCP state, Deep Color
setting, audio details and EDID information. To view the loopback settings:
• Turn the selection knob to highlight Loopback Settings and press th
ENTER button.
Loopback Settings
Loopback Settings
HDCP State: Inactive
Deep Color Mode: 8 bit
Audio
• Turn the selection knob to view the available informatio .
ailed information about the audio portion of the HDMI
he
n
Audio Details:
¾ To view det
output signal, turn the selection knob to highlight Audio and press t
ENTER button.
Operations Guide – DOC. 6755A 8x8 DigitalMedia™ Switcher: DM-MD8X8
• 73
Audio Settings The DMC-HD-DSP can display information about the audio portion of the incoming
