Appendix C: Output Configuration
This appendix contains detailed instructions for using the DM-MD8X8’s front panel
controls to configure the DigitalMedia outputs on a DM switcher.
To view/change the configuration settings for an output:
• Open the Outputs section of Installer Tools as described on page 28.
• Turn the selection knob to highlight the output to be configured and press
the ENTER button.
• To edit or view the details of an output, turn the selection knob to highlight
an output and press the ENTER button. A list of options is displayed. Turn
the selection knob to highlight an option and press the ENTER button.
Output Settings for Output 1
1. DMC-CATO-HD – CAT
Name: 1
DM Output Settings
HDMI Output Settings
• To return to the list of outputs, press the MENU button.
Name/Rename an Output To name and/or rename an output:
• Open the Outputs section and select an output as described above.
• Turn the selection knob to highlight the name of the output to be
named/renamed and press the ENTER button. A cursor will appear next to
the current name and controls for changing the name will also be displayed.
To cancel, press the MENU button.
Edit Output Name
Edit Output Name
Del < > Done
L iving Room
