Crestron DM-MD8X8 8x8 DigitalMedia™ Switcher
DM-MD8X8 Specifications (Continued)
SPECIFICATION DETAILS
Video (continued)
Formats
(determined by input cards)
Input Resolutions,
HDMI/DVI and RGB
Component
Composite and S-video
Output Resolutions
HDMI v.1.3a w/Deep Color, DVI v.1.0,
RGBHV up to UXGA/WUXGA, HDTV up to
1080p60, NTSC or PAL
640x480@60Hz, 720x480@60Hz (480p),
800x600@60Hz, 848x480@60Hz,
852x480@60Hz, 854x480@60Hz,
1024x768@60Hz, 1024x852@60Hz,
1024x1024@60Hz, 1280x720@60Hz
(720p60), 1280x768@60Hz,
1280x800@60Hz, 1280x960@60Hz,
1280x1024@60Hz, 1360x768@60Hz,
1365x1024@60Hz, 1366x768@60Hz,
1400x1050@60Hz, 1440x900@60Hz,
1600x900@60Hz, 1600x1200@60Hz,
1680x1050@60Hz, 1920x1080@60Hz
(1080p60), 1920x1200@60Hz,
2048x1080@24Hz, 2048x1152@60Hz, plus
any other resolution allowed by HDMI v.1.3a
480i, 576i, 480p, 576p, 720p50, 720p60,
1080i25 (1125 lines), 1080i30, 1080p24,
1080p25, 1080p30, 1080p50 (1125 lines),
1080p60
480i, 576i
Matched to inputs
Audio
Switcher
Input Signal Types
Output Signal Types
Formats
HDMI only
HDMI & SPDIF
Analog
8x8 digital multi-channel audio-follow-video
matrix switching, plus independent 8x8
stereo matrix for audio breakaway
Configurable via modular plug-in cards
supporting HDMI, analog (stereo or surround
encoded 2-channel), SPDIF, and DM over
copper wire or fiber
1
DM over copper wire or fiber*, and HDMI
(Some input cards also include analog pass-
thru audio outputs)
Dolby ® TrueHD 7.1, Dolby Digital Plus 7.1,
DTS-HD Master Audio™ 7.1, DTS-HD High
Res 7.1, 6ch PCM, 8ch PCM
Dolby Digital AC3 5.1, Dolby Digital EX 5.1,
DTS 5.1, DTS-ES Matrix 5.1, DTS-ES
Discrete 6.1, DTS 96/24 5.1, 2ch PCM
Stereo and Surround Encoded 2-Channel
(Continued on following page)
