Crestron DM-MD8X8

8x8 DigitalMedia™ Switcher

Calculate Power

CAUTION: Use only Crestron power supplies for Crestron equipment. Failure to
do so could cause equipment damage or void the Crestron warranty.

CAUTION: Provide sufficient power to the system. Insufficient power can lead
to unpredictable results or damage to the equipment. The EIG connector on the
DM switcher is used to jumper in external power. Additional power is rarely
required; switchers provide enough power for their maximum configuration of
room controllers and repeaters. Please use the DMNet Power Calculator to help
calculate how much power is needed for the system
(

www.crestron.com/calculators

).

Refer to the following table for maximum cable lengths for various cables.

Maximum Cable Length by Type

Cable Type:

DM-CBL DigitalMedia Cable

CresCAT-D Crestron
Home® CAT5 AV Cable

Resolution:

Maximum
length
between,
before, or
after
repeaters

Maximum
total length
using up to 3
repeaters

Maximum
length
between,
before, or
after
repeaters

Maximum
total length
using up to
3 repeaters

720p, 1080i, 1080p/24

200 ft (60 m)

450 ft (137 m)

150 ft (45 m)

400 ft (120 m)

1024x768 @75Hz

200 ft (60 m)

450 ft (137 m)

150 ft (45 m)

400 ft (120 m)

1080p/60

150 ft (45 m)

450 ft (137 m)

100 ft (30 m)

400 ft (120 m)

1280x1024 @75Hz

150 ft (45 m)

450 ft (137 m)

100 ft (30 m)

400 ft (120 m)

1920x1200 @60Hz

150 ft (45 m)

450 ft (137 m)

100 ft (30 m)

400 ft (120 m)

1600x1200 @60Hz

125 ft (38 m)

450 ft (137 m)

75 ft (23 m)

400 ft (120 m)

1080p/60 Deep Color

100 ft (30 m)

400 ft (120 m)

Not Supported

NOTE: All Crestron certified DMNet wiring must consist of two twisted pairs. One twisted pair is the +24V
conductor and the GND conductor and the other twisted pair is the A conductor and the B conductor.

Reference Documents

The latest version of all documents mentioned within the guide can be obtained from
the Crestron website (

www.crestron.com/manuals

). This link will provide a list of

product manuals arranged in alphabetical order by model number.

List of Related Reference Documents

DOCUMENT TITLE

Crestron DigitalMedia Design Guide

Crestron e-Control Reference Guide

Operations Guide – DOC. 6755A

8x8 DigitalMedia™ Switcher: DM-MD8X8
