Crestron DM-MD8X8

8x8 DigitalMedia™ Switcher

DMC-HD-DSP

The front panel controls for the DMC-HD-DSP allow the user to rename the input
and view information on the incoming HDMI source and the outgoing HDMI signal.

DMC-HD-DSP Controls

3. DMC-HD-DSP Advanc
Name: 3
Video Settings
Audio Settings

Using the DMC-HD-DSP controls, the user can:

• Change the input name.
• View details on the video portion of the incoming signal
• View details on the audio portion of the incoming signal.
• View details on the signal delivered to the HDMI OUT (loopback) port.
• View details about the device connected to the HDMI OUT (loopback)

port.

• View the status of the USB HID port.
• View the EDID mode setting.
• View the setting for the EDID maximum resolution.
• Show all of the EDID capabilities of the source device connected to the

HDMI IN port.

• Perform a Key Selection Vector (KSV) Limit Test to determine how many

endpoints can be connected to the source.

• Restore the input name to its default setting.

Name/Rename the Input

To name and/or rename the input:

• Turn the selection knob to highlight Name and press the ENTER button. A

cursor will appear next to the current name and controls for changing the
name will also be displayed. To cancel and return to the list of options for
the input card, press the MENU button.

Operations Guide – DOC. 6755A

8x8 DigitalMedia™ Switcher: DM-MD8X8

71
