Crestron DM-MD8X8 8x8 DigitalMedia™ Switcher
Info Mode
Use the Info mode to view information about the signal on an input or output.
Depending on the input selected, available information can include the name of the
input, the detected resolution, the detected video type, the detected frame rate, the
detected aspect ratio, the HDCP state, and the Deep Color setting. To select the Info
mode, press the INFO button. If an input port is receiving a signal from its
connected source, the accompanying LED will illuminate.
View Input Information • Press an input button to display information about the input signal. The
accompanying LED will flash.
NOTE: If the DMC-VID4 is selected, each composite video input can be
selected for viewing by pressing the soft button of the desired input.
• Turn the selection knob to display available information.
• Press another input button to view its information.
View Output Information
• Press an output button to display information about the output signal. The
accompanying LED will flash.
NOTE: If outputs 1 or 3 of a DMC-CATO-HD are selected, information
for the DM port and the HDMI port can be selected for viewing by pressing
the soft button of the desired output.
• Turn the selection knob to display available information.
• Press another output button to view its information.
Operations Guide – DOC. 6755A 8x8 DigitalMedia™ Switcher: DM-MD8X8
• 55
