Crestron DM-MD8X8

8x8 DigitalMedia™ Switcher

Control Functions

Control Setup
Backlight
Password
Front Panel Lock

Backlight

The brightness of the display’s backlight can be adjusted. To set the backlight level:

• Open the Control section as described on page 34.
• Turn the selection knob to highlight Backlight and press the ENTER

button to display the Backlight controls. The current setting is underlined.

Backlight Controls

Backlight

High

Med

Low

Select Backlight Level

• Press the soft button under the desired backlight brightness.
• Press the ENTER button to save the backlight brightness and return to the

Control section.

Password

The front panel password can be changed. To set a new password:

• Open the Control section as described on page 34.
• Turn the selection knob to highlight Password and press the ENTER

button to display the Password controls. The current password is displayed.

Operations Guide – DOC. 6755A

8x8 DigitalMedia™ Switcher: DM-MD8X8

35
