Crestron DM-MD8X8

8x8 DigitalMedia™ Switcher

• After the new name has been entered, press Done to save the name and

return to the Network section.

Control System Link

The front panel can display the status of the DM-MD8X8’s connection (“Online” or
“Offline”) to a control system (corresponding entries on the respective IP tables). To
view the status of the Control System Link:

• Open the Network section as described on page 29.
• Turn the selection knob to highlight Control System Link and press the

ENTER button to display the status of the connection between the
DM-MD8X8 and the control system.

• Press the MENU button to return to the Network section.

Control System IP ID

To properly function with a control system, the IP ID of the DM-MD8X8 must be set
to match the value specified in the SIMPL Windows program and the value on the
control system’s IP table. To view and set the IP ID:

• Open the Network section as described on page 29.
• Turn the selection knob to highlight Control System IP ID and press the

ENTER button to display the Control System IP ID controls. The current IP
ID will be displayed.

Control System IP ID

Edit Control System IP ID

A0

• Turn the selection knob to display the desired IP ID and press the ENTER

button to return to the Network section.

Control System IP Address

To properly function with a control system, the IP address of the control system that
is controlling the DM-MD8X8 must be provided to the DM-MD8X8. To view and
set the Control System IP Address:

• Open the Network section as described on page 29.
• Turn the selection knob to highlight Control System IP Address and press

the ENTER button to display the Control System IP Address controls. If
previously entered, the IP address of the control system will be displayed.

Operations Guide – DOC. 6755A

8x8 DigitalMedia™ Switcher: DM-MD8X8

33
