Video Settings
Video Settings
Video Type: Interlaced
Resolution: 1920x1080
Frame Rate: 30 fps
• Turn the selection knob to view the available information.
• Press the MENU button to return to the list of options for the input card.
Audio Settings The DMC-HD can display information about the audio portion of the incoming
signal. Available information includes format, frequency, and channels. To view
audio settings:
• Turn the selection knob to highlight Audio Settings and press the ENTER
button.
Audio Settings
Audio
Format: PCM
Frequency: 480kHz
Channels: 2
• Press the MENU button to return to the list of options for the input card.
Loopback Settings The DMC-HD can display information about the device connected to the HDMI
OUT port as well as information about the signal passed to the HDMI OUT port on
the DMC-HD. Available information includes HDCP state, Deep Color setting,
audio details and EDID information. To view the loopback settings:
• Turn the selection knob to highlight Loopback Settings and press the
ENTER button.
