8x8 DigitalMedia™ Switcher Crestron DM-MD8X8
DM-MD8X8 Specifications (Continued)
SPECIFICATION DETAILS
Ethernet
General
Switch
10/100/1000BaseT, auto-switching, auto-
negotiating, auto-discovery, full/half duplex,
TCP/IP, UDP/IP, CIP, DHCP, IEEE 803.U
compliant
(1) 10/100/1000BaseT Gigabit Ethernet port
(rear panel); (16) 10BaseT/100BaseTX
Ethernet ports (actual hardware ports are
exposed on select outboard devices)
USB
Switcher
Protocols
8x8 matrix
Supports USB HID class devices
Power Requirements
Main Power
Available DMNet Power
4 Amps @ 100-240 Volts AC, 50/60 Hz
55 Watts (2.3 Amps @ 24 Volts DC) from
internal power supply
Minimum 2-Series Control
System Update File
2,3
Version 4.001 or later
Environmental
Temperature
Humidity
Heat Dissipation
32º to 104º F (0º to 40º C)
10% to 90% RH (non-condensing)
475 BTU/Hr
Enclosure
Chassis
Faceplate
Mounting
Steel, black matte powder coat finish, vented
sides, fan-cooled
Extruded aluminum, black matte powder
coat finish with polycarbonate label overlay
Freestanding or 4U 19-inch rack-mountable
(adhesive feet and rack ears included)
Dimensions (without cards)
Height
Width
Depth
6.97 in (17.68 cm)
17.28 in (43.90 cm)
18.06 in (45.87 cm)
Weight 20.0 lbs (9.1 kg)
(Continued on following page)
8
• 8x8 DigitalMedia™ Switcher: DM-MD8X8
Operations Guide – DOC. 6755A
