Fabric OS Administrator’s Guide
73
53-1002745-02
Domain IDs
2
Displaying the domain IDs
Use the following procedure to display device domain IDs:
1. Connect to the switch and log in using an account assigned to the admin role.
2. Enter the fabricShow command.
Example output of fabric information, including the domain ID (D_ID)
The principal switch is determined by the arrow ( > ) next to the name of the switch. In this
output, the principal switch appears in blue boldface.
switch:admin> fabricshow
Switch ID
Worldwide Name
Enet IP Addr
FC IP Addr
Name
-------------------------------------------------------------------------
2:
fffc02
10:00:00:60:69:e0:01:46
10.3.220.1
0.0.0.0
"ras001"
3:
fffc03
10:00:00:60:69:e0:01:47
10.3.220.2
0.0.0.0
"ras002"
5:
fffc05
10:00:00:05:1e:34:01:bd
10.3.220.5
0.0.0.0
"ras005"
fec0:60:69bc:63:205:1eff:fe34:1bd
6:
fffc06
10:00:00:05:1e:34:02:3e
10.3.220.6
0.0.0.0
"ras006"
7:
fffc07
10:00:00:05:1e:34:02:0c
10.3.220.7
0.0.0.0
"ras007"
10:
fffc0a
10:00:00:05:1e:39:e4:5a
10.3.220.10
0.0.0.0
"ras010"
15:
fffc0f
10:00:00:60:69:80:47:74
10.3.220.15
0.0.0.0
"ras015"
19:
fffc13
10:00:00:05:1e:34:00:ad
10.3.220.19
0.0.0.0
"ras019"
fec0:60:69bc:63:219:1eff:fe34:1bd
20:
fffc14
10:00:00:05:1e:40:68:78
10.3.220.20
0.0.0.0
"ras020"
25:
fffc19
10:00:00:05:1e:37:23:c6
10.3.220.25
0.0.0.0
"ras025"
30:
fffc1e
10:00:00:60:69:90:04:1e
10.3.220.30
0.0.0.0
"ras030"
35:
fffc23
10:00:00:05:1e:07:c7:26
10.3.220.35
0.0.0.0
"ras035"
40:
fffc28
10:00:00:60:69:50:06:7f
10.3.220.40
0.0.0.0
"ras040"
45:
fffc2d
10:00:00:05:1e:35:10:72
10.3.220.45
0.0.0.0
"ras045"
46:
fffc2e
10:00:00:05:1e:34:c5:17
10.3.220.46
0.0.0.0
"ras046"
47:
fffc2f
10:00:00:05:1e:02:aa:f7
10.3.220.47
0.0.0.0
"ras047"
50:
fffc32
10:00:00:60:69:c0:06:64
10.1.220.50
0.0.0.0
"ras050"
(output truncated)
The Fabric has 26 switches
displays the fabricShow fields.
TABLE 4
fabricShow fields
Field Description
Switch ID
The switch domain_ID and embedded port D_ID. The numbers are broken down as follows:
Example 64: fffc40
64 is the switch domain_ID
fffc40 is the hexadecimal format of the embedded port D_ID.
World Wide Name The switch WWN.
Enet IP Addr
The switch Ethernet IP address for IPv4- and IPv6-configured switches. For IPv6 switches, only
the static IP address displays.
FC IP Addr
The switch Fibre Channel IP address.
Name
The switch symbolic or user-created name in quotes.
