OCI Commands B–5
Publication 8520-6.6. - August 1999
Inst
ID
P3 type Parameter 3 P2 type Parameter 2 P1 type Parameter 1 Dual
Proc.
# Params OCI / 9/PC Control Type Command Description Item (Name)
122 VERIFY_WITH_PORTB Verifies part program with port B All Controls OCI 2 Yes File Name STRING1 Test(0)/Exec(1) DINT
Part Program Execution
117 ENTER_MIDSTART_SEARCH_MODE Enters midstart search mode All Controls Both 1 Yes Midstart Type enum DINT
118 EXECUTE_MIDSTART_SEARCH Executes midstart search All Controls Both 1 Yes Midstart Search Mode
enum
DINT
119 SET_MIDSTART_SEARCH_PATTERN Sets midstart seach pattern All Controls Both 1 Yes Search Pattern STRING1
38 STOP_QUICK_CHECK Stops Quick Check All Controls Both Yes File Name STRING1
37 SYNTAX_QUICK_CHECK Quick Checks syntax All Controls Both Yes
Tool Management/Random Tool
26 ACTIVATE_RANDOM_TOOL Activates random tool "Lathe, Mill,
Dual"
Both 3 Yes Tool Number DINT Pockets Needed DINT Shaft Pocket DINT
25 BACKUP_RANDOM_TOOL Backup random tool data to part program "Lathe, Mill,
Dual"
Both 1 Yes File Name STRING1
24 BACKUP_TOOL_MANAGE Backup tool management data to part program "Lathe, Mill,
Dual"
Both 1 Yes File Name STRING1
111 RT_CUSTOMIZE_TOOL Customize random tool pocket "Lathe, Mill,
Dual"
Both 3 Yes Pocket Number DINT Pockets Needed DINT Shaft Pocket DINT
110 RT_SET_TOOL_NUM Assign random tool number to pocket "Lathe, Mill,
Dual"
Both 2 Yes Tool Number DINT Number of Pockets DINT
98 TM_DELETE_ALL Delete all the tool management groups "Mill, Dual Mill" Both Yes
95 TM_DELETE_GROUP Delete tool group in tool management "Mill, Dual Mill" Both 1 Yes Tool Group Number DINT
97 TM_DELETE_TOOL Delete tool from tool management group "Mill, Dual Mill" Both 2 Yes Tool Group Number DINT Entry Number DINT
96 TM_INSERT_TOOL Insert tool into tool management group "Mill, Dual Mill" Both 3 Yes Tool Group Number DINT Tool Number DINT Entry Number (where to
put tool)
DINT
54 TRANSFER_PAL_TO_PORTB PAL and I/O to port B All Controls Both No
Paramacro Commands
36 BACKUP_ALL_PARAMETERS Backup all paramacro parameters All Controls Both 1 Yes File Name STRING1
32 BACKUP_COM1_PARAMETERS Backup Com-1 paramacro parameters All Controls Both 1 Yes File Name STRING1
33 BACKUP_COM2A_PARAMETERS Backup Com-2A paramacro parameters All Controls Both 1 Yes File Name STRING1
34 BACKUP_COM2B_PARAMETERS Backup Com-2B paramacro parameters All Controls Both 1 Yes File Name STRING1
35 BACKUP_SHARED_PARAMETERS Backup Shared paramacro parameters Dual Both 1 Yes File Name STRING1
103 CLEAR_COM_NAME Clears all paramacro com2a names All Controls Both 1 Yes Param Index (0 - all) DINT
104 ZERO_ALL_COM_VALUES Sets specified paramacro com params to zero All Controls Both 1 Yes Com Table (enum) DINT
Part Program Commands
2 ACTIVATE_PART_PROGRAM Activates part program All Controls Both 1 Yes File Name STRING1
152 CHECK_IF_FILE_PRESENT Checks for exsitance of file All Controls Both No
8 COPY_PART_PROGRAM Copies part program All Controls Both 2 No Source Name STRING1 Destination Name STRING1
