OCI Data Items A–14
Publication 8520-6.6. - August 1999
Control Type Req Dual
Proc.
Units
Dependency
Units Array Indices Num
Indices
OCI/9/PC Data Type Description Item (Name)
327
PROBE_ENTRY_UNITS
Units for touch probe data entry INT (inch/metric)
enum
Both 0 Yes R/W Mill, DMill
280 PROBE_FEEDRATE
Probe cycle feedrate (F) - Online AMP LREAL Both 1 Probe Entry Units Inch/MetĆ
ric/DeĆ
grees
Metric units always
(mm/sec)
Yes R/W Mill, DMill
281
PROBE_LENGTH
Probe length for compensation - Online AMP LREAL Both 1 Probe Entry Units Inch/MetĆ
ric/DeĆ
grees
Metric units always
(mm)
Yes R/W Mill, DMill
282
PROBE_RADIUS
Probe radius for compensation - Online AMP LREAL Both 1 Probe Entry Units Inch/MetĆ
ric/DeĆ
grees
Metric units always
(mm)
Yes R/W Mill, DMill
278 PROBE_TOLERANCE_BAND
Probing cycles compensation (B) - Online AMP LREAL Both 1 Probe Entry Units Inch/MetĆ
ric/DeĆ
grees
Metric units always
(mm)
Yes R/W Mill, DMill
s Program Block Items
48 ACTIVE_PART_PROGRAM_BLOCKS Active Part Program Blocks STRING1 [ ] Both 1 Num setupbuffers Yes R All Controls
37 N_WORD Programmed N-Word
(from the letter table)
DINT Both 0 Yes R All Controls
7 NUM_SETUP_BUFFERS Num setupbuffers DINT Max Value 21 Both 0 No R All Controls
t Random Tool and Tool Life Management
194 ACTIVE_RANDOM_TOOL_NUM Active random tool number INT Both 0 Yes R Lathe, Mill, Dual
195 ACTIVE_RANDOM_TOOL_NUM_POCKETS Number of pockets for active random tool USINT Both 0 Yes R Lathe, Mill, Dual
196 ACTIVE_RANDOM_TOOL_SHAFT_POCKET Shaft pocket number of active random tool USINT Both 0 Yes R Lathe, Mill, Dual
197 NUM_AMP_PARAMETERS Number of AMP Parameters UINT Both 0 No R All Controls
178 NUM_POCKETS Number of tool pockets -- AMP UINT Both 0 Yes R All Controls
224 RT_POCKETS_NEEDED Random tool pockets needed USINT [ ] Both 1 MAX_NUMĆ
BER_POCKETS
Yes R Lathe, Mill
225 RT_SHAFT_POCKET Random tool shaft pocket USINT [ ] Both 1 MAX_NUMĆ
BER_POCKETS
Yes R Lathe, Mill
223 RT_TOOL_NUM Random tool number INT [ ] Both 1 MAX_NUMĆ
BER_POCKETS
Yes R Lathe, Mill
213 TM_ACTIVE_ENTRY Active tool management tool entry INT Both 0 Yes R Lathe, Mill, Dual
212 TM_ACTIVE_TOOL Active tool management tool INT Both 0 Yes R Lathe, Mill, Dual
211 TM_ACTIVE_TOOL_GROUP Active tool management tool group INT Both 0 Yes R Lathe, Mill, Dual
220 TM_ACCUMULATED_LIFE Tool management data accumulated life REAL [ ] Both 1 MAX_TOOL_ENĆ
TRIES
Yes R/W Lathe, Mill
