OCI Data Items
A–19
Publication 8520-6.6. - August 1999
Control Type
Req
Dual
Proc.
Units
Dependency
Units
Array Indices
Num
Indices
OCI/9/PC
Data Type
Description
Item (Name)
88
G593_WORK_COORD
G59.3 Work Coordinate
LREAL [ ]
Both
1
Num Axes
Inch/MetĆ
ric/DeĆ
grees
G593_WORK_CO
ORD_UNITS
Yes
R/W
All Controls
89
G593_WORK_COORD_UNITS
G59.3 Work Coordinate Units
INT
Both
0
Yes
R/W
All Controls
345
PLANE E_AXES_INDICES
Bit pattern of axes in currently active plane
INT[ ]
Both
Yes
R
All Controls
202
WORK_COORD_LABELS
Labels for work coordinates
STRING1 [ ]
Both
1
MAX_WORK_CO
ORD
No
R/W
Grinder
y
Zones and Overtravels
265
INTERF_FIRST_AXIS_MINUS_AREA_1
Interference zones first axis minus limit for dual
process interference zone 1
LREAL [ ]
OCI
1
Interf Tool Number
Inch/MetĆ
ric/DeĆ
grees
INTERF_UNITS [
Interf Tool Number
]
Yes
R/W
Dual
264
INTERF_FIRST_AXIS_PLUS_ AREA_1
Interference zones first axis plus limit for dual
process interference zone 1
LREAL [ ]
OCI
1
Interf Tool Number
Inch/MetĆ
ric/DeĆ
grees
INTERF_UNITS [
Interf Tool Number
]
Yes
R/W
Dual
267
INTERF_SECOND_AXIS_MINUS_AREA_1
Interference zones second axis minus limit for
dual process interference zone 1
LREAL [ ]
OCI
1
Interf Tool Number
Inch/MetĆ
ric/DeĆ
grees
INTERF_UNITS [
Interf Tool Number
]
Yes
R/W
Dual
266
INTERF_SECOND_AXIS_PLUS_AREA_1
Interference zones second axis plus limit for
dual process interference zone 1
LREAL [ ]
OCI
1
Interf Tool Number
Inch/MetĆ
ric/DeĆ
grees
INTERF_UNITS [
Interf Tool Number
]
Yes
R/W
Dual
331
INTERF_FIRST_AXIS_MINUS_AREA_2
Interference zones first axis minus limit for dual
process interference zone 2
LREAL [ ]
OCI
1
Interf Tool Number
Inch/MetĆ
ric/DeĆ
grees
INTERF_UNITS [
Interf Tool Number
]
Yes
R/W
Dual
330
INTERF_FIRST_AXIS_PLUS_ AREA_2
Interference zones first axis plus limit for dual
process interference zone 2
LREAL [ ]
OCI
1
Interf Tool Number
Inch/MetĆ
ric/DeĆ
grees
INTERF_UNITS [
Interf Tool Number
]
Yes
R/W
Dual
333
INTERF_SECOND_AXIS_MINUS_AREA_2
Interference zones second axis minus limit for
dual process interference zone 2
LREAL [ ]
OCI
1
Interf Tool Number
Inch/MetĆ
ric/DeĆ
grees
INTERF_UNITS [
Interf Tool Number
]
Yes
R/W
Dual
332
INTERF_SECOND_AXIS_PLUS_AREA_2
Interference zones second axis plus limit for
dual process interference zone 2
LREAL [ ]
OCI
1
Interf Tool Number
Inch/MetĆ
ric/DeĆ
grees
INTERF_UNITS [
Interf Tool Number
]
Yes
R/W
Dual
177
INTERF_TOOL_NUM
Number of Interference tools -- AMP
UINT
OCI
0
Yes
R
All Controls
114
LIMIT2_LOWER_LIMITS
Limit 2 Lower Limit
LREAL [ ]
OCI
1
Num Axes
Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS
Yes
R/W
All Controls
115
LIMIT2_UPPER_LIMITS
Limit 2 Upper Limit
LREAL [ ]
OCI
1
Num Axes
Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS
Yes
R/W
All Controls
