OCI Data Items A–7
Publication 8520-6.6. - August 1999
Control Type Req Dual
Proc.
Units
Dependency
Units Array Indices Num
Indices
OCI/9/PC Data Type Description Item (Name)
170 DRESSER_ROLL_DIAMETER Dresser roll diameter LREAL OCI 0 Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS No R/W Grinder
160 DRESSER_STATUS Dresser Status UINT OCI 0 No R Grinder
173 DRESSER_SURFACE_SPEED_ RATIO Dresser surface speed ratio LREAL OCI 0 No R/W Grinder
326 DRESSER_TABLE_UNITS Units for over the wheel dresser data entry UINT (inch/metric)
enum
OCI 0 No R/W Grinder
162 INITIAL_WHEEL_DIAMETER Initial wheel diameter LREAL OCI 0 Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS No R Grinder
168 MAX_WHEEL_SPEED Maximum wheel speed (RPM) LREAL OCI 0 Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS No R/W Grinder
167 MIN_WHEEL_DIAMETER Minimum wheel diameter LREAL - AMP OCI 0 Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS No R/W Grinder
165 NEW_WHEEL_DIAMETER New wheel diameter LREAL OCI 0 Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS No R/W Grinder
166 WARNING_WHEEL_DIAMETER Warning wheel diameter LREAL OCI 0 Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS No R/W Grinder
169 WHEEL_WIDTH Wheel width LREAL OCI 0 Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS No R/W Grinder
j Miscellaneous System Information
15 BOOT_FW_REVISION Boot Firmware Revision STRING1 Both 0 No R All Controls
13 COPYRIGHT_DATE Copyright Date STRING1 Both 0 No R All Controls
118 CALCULATION_RESULTS Returned results from CALCULATE command LREAL Both 0 No R All Controls
336 CONTROLLING_OCI True (1) indicates this station is the data server
controlling station (not necissarily controlling
file server)
USINT OCI 0 No R All Controls
146 DATASCOPE_DATA Data Scope Monitor serial port data USINT [ ] OCI 130 No R All Controls
62 DATE Current Date STRING1 Both 0 No R/W All Controls
337 DOWNLOAD_IN_PROGRESS Downloading AMP/PAL status INT (enumerated) Both No R All Controls
343 ESTOP_STATE 0 - control in E-STOP,
1 - control out of E-STOP
USINT Both No R All Controls
14 FW_REVISION Firmware Revision DINT Both 0 No R All Controls
318 IFP_COPY_CANCEL A write parameter to cancel copy in progress UINT Both 1 No R/W All Controls
