OCI Data Items A–18
Publication 8520-6.6. - August 1999
Control Type Req Dual
Proc.
Units
Dependency
Units Array Indices Num
Indices
OCI/9/PC Data Type Description Item (Name)
340 ACTIVE_PLANE_AXES Bit pattern of axes in active plane DINT Both Yes R All Controls
90 EXTERNAL_WORK_COORD External Work Coordinate LREAL [ ] Both 1 Num Axes Inch/MetĆ
ric/DeĆ
grees
EXTERĆ
NAL_WORK_COO
RD_UNITS
Yes R/W All Controls
91 EXTERNAL_WORK_COORD_ UNITS External Work Coordinate Units INT Both 0 Yes R/W All Controls
72 G54_WORK_COORD G54 Work Coordinate LREAL [ ] Both 1 Num Axes Inch/MetĆ
ric/DeĆ
grees
G54_WORK_COO
RD_UNITS
Yes R/W All Controls
73 G54_WORK_COORD_UNITS G54 Work Coordinate Units INT Both 0 Yes R/W All Controls
74 G55_WORK_COORD G55 Work Coordinate LREAL [ ] Both 1 Num Axes Inch/MetĆ
ric/DeĆ
grees
G55_WORK_COO
RD_UNITS
Yes R/W All Controls
75 G55_WORK_COORD_UNITS G55 Work Coordinate Units INT Both 0 Yes R/W All Controls
76 G56_WORK_COORD G56 Work Coordinate LREAL [ ] Both 1 Num Axes Inch/MetĆ
ric/DeĆ
grees
G56_WORK_COO
RD_UNITS
Yes R/W All Controls
77 G56_WORK_COORD_UNITS G56 Work Coordinate Units INT Both 0 Yes R/W All Controls
78 G57_WORK_COORD G57 Work Coordinate LREAL [ ] Both 1 Num Axes Inch/MetĆ
ric/DeĆ
grees
G57_WORK_COO
RD_UNITS
Yes R/W All Controls
79 G57_WORK_COORD_UNITS G57 Work Coordinate Units INT Both 0 Yes R/W All Controls
80 G58_WORK_COORD G58 Work Coordinate LREAL [ ] Both 1 Num Axes Inch/MetĆ
ric/DeĆ
grees
G58_WORK_COO
RD_UNITS
Yes R/W All Controls
81 G58_WORK_COORD_UNITS G58 Work Coordinate Units INT Both 0 Yes R/W All Controls
82 G59_WORK_COORD G59Work Coordinate LREAL [ ] Both 1 Num Axes Inch/MetĆ
ric/DeĆ
grees
G59_WORK_COO
RD_UNITS
Yes R/W All Controls
83 G59_WORK_COORD_UNITS G59 Work Coordinate Units INT Both 0 Yes R/W All Controls
84 G591_WORK_COORD G59.1 Work Coordinate LREAL [ ] Both 1 Num Axes Inch/MetĆ
ric/DeĆ
grees
G591_WORK_CO
ORD_UNITS
Yes R/W All Controls
85 G591_WORK_COORD_UNITS G59.1 Work Coordinate Units INT Both 0 Yes R/W All Controls
86 G592_WORK_COORD G59.2 Work Coordinate LREAL [ ] Both 1 Num Axes Inch/MetĆ
ric/DeĆ
grees
G592_WORK_CO
ORD_UNITS
Yes R/W All Controls
87 G592_WORK_COORD_UNITS G59.2 Work Coordinate Units INT Both 0 Yes R/W All Controls
