OCI Data Items A–15
Publication 8520-6.6. - August 1999
Control Type Req Dual
Proc.
Units
Dependency
Units Array Indices Num
Indices
OCI/9/PC Data Type Description Item (Name)
218 TM_CUTTER_COMP_NUM Tool management data cutter comp number USINT [ ] Both 1 MAX_TOOL_ENĆ
TRIES
Yes R/W Lathe, Mill
216 TM_ENTRY_NUM Tool management data entry number USINT [ ] Both 1 MAX_TOOL_ENĆ
TRIES
Yes R Lathe, Mill
221 TM_EXPECTED_LIFE Tool management data expected tool life REAL [ ] Both 1 MAX_TOOL_ENĆ
TRIES
Yes R/W Lathe, Mill
222 TM_GRAPHICS_TOOL_COLOR Tool management data graphics tool color USINT [ ] enumerated Both 1 MAX_TOOL_ENĆ
TRIES
Yes R/W Lathe, Mill
215 TM_GROUP_NUM Tool management data group number INT [ ] Both 1 MAX_TOOL_ENĆ
TRIES
Yes R Lathe, Mill
219 TM_STATUS Tool management data status USINT [ ] Both 1 MAX_TOOL_ENĆ
TRIES
Yes R Lathe, Mill
208 TM_TOOL_GROUP_LIFE_TYPE Tool management group life type USINT [ ] Both 1 MAX_TOOL_GRO
UPS
Yes R/W Lathe, Mill
209 TM_TOOL_GROUP_THLD_RATE Tool management group threshold rate USINT [ ] Both 1 MAX_TOOL_GRO
UPS
Yes R/W Lathe, Mill
214 TM_TOOL_NUM Tool management data tool number INT [ ] Both 1 MAX_TOOL_ENĆ
TRIES
Yes R Lathe, Mill
217 TM_TOOL_OFFSET_NUM Tool management data tool offset number USINT [ ] Both 1 MAX_TOOL_ENĆ
TRIES
Yes R/W Lathe, Mill
210 TM_TOOLS_PER_GROUP Number of tools in each valid tool group USINT [ ] Both 1 MAX_TOOL_GRO
UPS
Yes R Lathe, Mill, Dual
339 TM_UPDATE_IN_PROGRESS True if tool management update is in progress INT Both Yes R All Controls
u Servo Information
342 ANGLED_WHEEL_ALLOWED True if system supports angled wheel mode INT [ ] OCI Yes R Grinder
21 AXIS_NAME Displayed Axis Names Per Process STRING1 [ ] Both 1 Num Axes Yes R All Controls
346 AXIS_PRESENT_LOGICAL_BIT_PATTERN Bit pattern of axes in currently active plane UDINT Both Yes R All Controls
368 NUM_1394_RACKS Number of 1394 racks connected to the CNC UINT 9/PC 0 No R All Controls
2 NUM_AXES Num Axes num_rv_axes UINT Max Value 12 Both 0 Yes R All Controls
315 NUM_MONITORED_SERVOS # of servos monitored (prog axes+skew
slaves+spindle)
UINT Both 0 Yes R All Controls
341 NUM_PROG_AXES_PLUS_EXTRA Num programming axis (inc. duals, and angled
virtual axes)
UINT Both 0 Yes R All Controls
1 NUM_SERVO_MODULES Num Servo Modules UINT Max Value 3 OCI 0 No R All Controls
9 NUM_SERVOS Num Servos (inc. deskew and depth probe) UINT Max Value 15 Both 0 Yes R All Controls
335 NUM_SERVOS_PLUS_SPINDLES Number of servos plus the number of spindles INT Max Value 15 Both 0 Yes R All Controls
268 NUM_SKEWSLAVES Num of skew slaves in the process INT Both Yes R All Controls
