OCI Data Items A–6
Publication 8520-6.6. - August 1999
Control Type Req Dual
Proc.
Units
Dependency
Units Array Indices Num
Indices
OCI/9/PC Data Type Description Item (Name)
32
FEED_VALUE
Feedrate Value LREAL Both 0 IPM/
MMPM,
IPR/
MMPR,
V/D
ACTIVE_UNITS,
FEED_MODE
Yes R All Controls
g Fixed Cycles
285 BACK_BORING_SHIFT_DIRECTION Shift direction for back boring cycles - Online
AMP
STRING1 [ ] Both 3 Yes R/W All Controls
284 DRILLING_CLEARANCE_ AMOUNT Clearance amount for drilling cycles - Online
AMP
LREAL Both 0 Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS No R/W All Controls
283 DRILLING_RETRACT_AMOUNT Retract amount for drilling cycles - Online AMP LREAL Both 0 Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS No R/W All Controls
288 THREADING_PULLOUT_ANGLE Pullout angle for threading cycles - Online AMP LREAL Both 0 Degrees always No R/W Lathe,DLathe
287 THREADING_PULLOUT_DISTANCE Pullout distance for threading cycles - Online
AMP
LREAL Both 0 Thread units No R/W Lathe,DLathe
h G and M Code Data
29 G_CODE_STATUS G Code Status INT [ ] Both 1 Num G groups Yes R All Controls
30 G_GROUP_PROGRAMMED G Group Programmed DINT bit pattern Both 0 Num G groups Yes R All Controls
27 M_CODE_STATUS M Code Status INT [ ] Both 1 Num M groups Yes R All Controls
28 M_GROUP_PROGRAMMED M Group Programmed DINT bit pattern Both 0 Num M groups Yes R All Controls
6 NUM_G_GROUPS Num G groups UINT Max Value 23 Both 0 No R All Controls
5 NUM_M_GROUPS Num M groups UINT Max Value 14 Both 0 No R All Controls
40 SECONDARY_AUX_WORD Secondary Auxiliary word Value DINT Both 0 Yes R All Controls
i In Process Dresser
164 CURRENT_DRESSER_RPM Current dresser RPM LREAL OCI 0 RPM No R Grinder
163 CURRENT_WHEEL_DIAMETER Current wheel diameter LREAL OCI 0 Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS No R Grinder
171 DRESSER_AMOUNT_PER_REV Dresser amount per rev LREAL OCI 0 Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS No R/W Grinder
161 DRESSER_HOLD_STATUS Dresser Hold Status UINT OCI 0 No R Grinder
172 DRESSER_RETRACT_
DISTANCE
Dresser retract distance LREAL OCI 0 Inch/MetĆ
ric/DeĆ
grees
ACTIVE_UNITS No R/W Grinder
