Rockwell Automation Publication 1768-UM002C-EN-P - April 2012

93

Chapter

7

Go Online with the Controller

Connecting the Controller to
the Network

If you have not done so, connect the controller to the network.

Connect the Controller via a Serial Network

The 1756-CP3 or 1747-CP3 cable attaches the serial port of the workstation
directly to the controller.

Topic

Page

Connecting the Controller to the Network

93

Configuring the Network Driver

94

Understanding the Factors that Affect Going Online

95

Download

98

Upload

100

Go Online

101

Table 25 - Network Connections

For this network

Connect the controller via a

Serial

1756-CP3 or 1747-CP3 cable

EtherNet/IP

1768-ENBT module to the left of the Compact GuardLogix controller

ControlNet

1768-CNB module to the left of the Compact GuardLogix controller

WARNING: If you connect or disconnect the serial cable with power
applied to this module or the serial device at the end of the cable, an
electrical arc can occur. This could cause an explosion in hazardous
location installations.

Be sure that power is removed or the area is nonhazardous before
proceeding.
