Rockwell Automation Publication 1768-UM002C-EN-P - April 2012

Chapter 8

Monitor Status and Handle Faults

Table 32 - GSV/SSV Accessibility

Safety
Object

Attribute Name

Data Type

Attribute Description

Accessible from

the Safety Task

Accessible from

Standard Tasks

GSV

SSV

GSV

(4)

SSV

Safety Task

Instance

DINT

Provides instance number of this task object. Valid values are
0…31.

MaximumInterval

DINT[2]

The max time interval between successive executions of this task.

MaximumScanTime

DINT

Max recorded execution time (ms) for this task.

MinimumInterval

DINT[2]

The min time interval between successive executions of this task.

Priority

INT

Relative priority of this task as compared to other tasks. Valid
values are 0…15.

Rate

DINT

Period for the task (in ms), or timeout value for the task (in ms).

Watchdog

DINT

Time limit (in ms) for execution of all programs associated with this
task.

Safety
Program

Instance

DINT

Provides the instance number of the program object.

MajorFaultRecord

(1)

DINT[11]

Records major faults for this program.

MaximumScanTime

DINT

Max recorded execution time (ms) for this program.

Safety
Routine

Instance

DINT

Provides the instance number for this routine object. Valid values
are 0…65,535.

Safety
Controller

SafetyLocked

SINT

Indicates whether the controller is safety-locked or -unlocked.

SafetyStatus

(2)

INT

Specifies the safety status as the following:

Safety task OK. (1000000000000000)
Safety task inoperable. (1000000000000001)
Firmware incompatible. (00000000000000011)

SafetySignatureExists

SINT

Indicates whether the safety task signature is present.

SafetySignatureID

DINT

32-bit identification number.

SafetySignature

String

(3)

32-bit identification number.

SafetyTaskFaultRecord

(1)(2)

DINT[11]

Records safety task faults.

AOI (Safety)

LastEditDate

LINT

Date and time stamp of the last edit to an Add-On Instruction
definition.

SignatureID

DINT

ID number.

SafetySignatureID

DINT

32-bit identification number.

(1) See

Access FaultRecord Attributes on page 111

for information on how to access this attribute.

(2) See

Capture Fault Information on page 111

for information on how to access this attribute.

(3) Length = 37.
(4) From the standard task, GSV accessibility of safety object attributes is the same as for standard object attributes.
