16

Rockwell Automation Publication 1768-UM002C-EN-P - April 2012

Chapter 1

System Overview

Compact GuardLogix controllers support 1768-M04SE SERCOS modules for
motion control in standard (non-safety) applications. For information on
developing motion applications, refer to the SERCOS and Analog Motion
Configuration and Startup Manual, publication

MOTION-UM001

.

Compact GuardLogix controllers also support PhaseManager™ programs, which
let you add equipment phases to standard controller applications. Refer to the
PhaseManager User Manual, publication

LOGIX-UM001

, for more

information.

For information on using these features, refer to the Logix5000 Controllers
Common Procedures Programming Manual, publication

1756-PM001

, the

publications listed in the

Additional Resources on page 9

, and RSLogix 5000

software online help.

Table 3 - Supported Features by RSLogix 5000 Software Version

Feature

Version 18

Version 19

Version 20

Safety Task

Standard Task Safety Task

Standard Task Safety Task

Standard Task

Add-On instructions

X

X

X

X

X

X

Alarms and events

X

X

X

Constant value tags

X

X

X

X

X

X

Equipment phase routines

X

X

X

External Access

X

X

X

X

X

X

Event tasks

X

X

X

Firmware Supervisor

X

X

X

X

X

X

Function block diagrams (FBD)

X

X

X

Integrated motion

X

X

X

Ladder logic

X

X

X

X

X

X

Language switching

X

X

X

X

X

X

Online import and export of program components

X

X

X

Sequential function chart (SFC) routines

X

X

X

Structured text

X

X

X

Unicast connections for produced and consumed safety tags

X

X

X

X

Unicast connections for safety I/O modules

X

X
