Chapter 5

Add, Configure, Monitor, and Replace CIP Safety I/O

Table 15 - Status Indicator Operation

Indicator

Status

Description

EtherNet/IP Modules

Module Status (MS)

Off

No power.

Green, On

Operating under normal conditions.

Green, Flashing

Device is idle.

Red, Flashing

A recoverable fault exists or a firmware update is in progress.

Red, On

An unrecoverable fault exists.

Red/Green, Flashing

Self-tests are in progress or the module is not configured
properly. See the network status indicator for more information.

Network Status (NS)

Off

Device is not online or may not have power.

Green, On

Device is online; connections are established.

Green, Flashing

Device is online; no connections established.

Red, Flashing

Communication timeout or a firmware update is in progress.

Red, On

Communication failure. The device has detected an error that
has prevented network communication.

Red/Green, Flashing

Self-test in progress.

Input Points
(INx)

Off

Safety input is OFF.

Yellow, On

Safety input is ON.

Red, On

An error has occurred in the input circuit.

Red, Flashing

When dual-channel operation is selected, an error has occurred
in the partner input circuit.

Output Points (Ox)

Off

Safety output is OFF.

Yellow, On

Safety output is ON.

Red, On

An error has occurred in the output circuit.

Red, Flashing

When dual-channel operation is selected, an error has occurred
in the partner output circuit.

IN PWR

Green, Off

No input power.

Green, On

Input power voltage is within specification.

Yellow, On

Input power voltage is out of specification.

OUT PWR

Green, Off

No output power.

Green, On

Output power voltage is within specification.

Yellow, On

Output power voltage is out of specification.

Test Output Points (Tx) Off

The output is OFF.

Yellow, On

The output is ON.

Red. On

An error has occurred in the output circuit.
