Design Guide & Applications Manual
For Maxi, Mini, Micro Family DC-DC Converters and Configurable Power Supplies
Maxi, Mini, Micro Design Guide Rev 4.9 vicorpower.com
Page 54 of 88
Apps. Eng. 800 927.9474 800 735.6200
11. Filter Input Attenuator Module (FIAM) Family
FIAM1 FIAM2 M-FIAM3 Notes
Input voltage 36 – 76 Vdc 36 – 76 Vdc 180 – 375 Vdc Continuous
Recommended fusing (F1): Bussman ABC–10 Bussman ABC-20 Bussman ABC-3
Output current: 10 A 20 A 3 A Maximum
External capacitance (C1) 10 µF min – 150 µF max 100 µF min – 330 µF max 10 µF min – 22 µF max
Inrush limiting 0.014 A/µF 0.014 A/µF 0.018 A/µF Maximum
EMI/RFI
Bellcore GR-001089-Core, Bellcore GR-001089-Core, MIL-STD-461E, CE101
EN55022 Class B, FCC EN55022 Class B, FCC CE102, CS101, CS114
Part 15 Class B Part 15 Class B CS115, CS116
Transient immunity
Bellcore TR-NWT-0004999, Bellcore TR-NWT-0004999, Exceeds limits of MIL-STD-
ETS 300 386-1, Class 2 ETS 300 386-1, Class 2 704E/F
Mini package size 2.28" x 2.2" x 0.5" 2.28" x 2.2" x 0.5" 2.28" x 2.2" x 0.5"
Table 11–1 — FIAM Family Specifications (See specific data sheets for more detail)
M-FIAM5B M-FIAM9 Notes
Input voltage 14 – 36 Vdc 10 – 36 Vdc Continuous
Recommended fusing (F1): Bussman ABC-20 Bussman ABC-20
Output current: 20 A 18 A Maximum
External capacitance (C1) 330 µF min –1000 µF max 330 µF min –1000 µF max
Inrush limiting 0.007 A/µF 0.007 A/µF Maximum
EMI/RFI
MIL-STD-461E, CE101 MIL-STD-461E, CE101
CE102, CS101, CS114 CE102, CS101, CS114
CS115, CS116 CS115, CS116
Transient immunity
50 V Max. 12.5 ms per MIL- 100 Vdc 50 ms per MIL-STD-
STD-704E/F, cont. operation 1275A/B/D, 250 Vdc 70 µs
per MIL-STD-1275A/B/D, 70
Vdc 20 ms per MIL-STD-704A.
50 Vdc 12.5 ms per MIL-STD-
704E/F, cont. operation
Mini package size 2.28" x 2.2" x 0.5" 2.28" x 2.2" x 0.5"
