3. Design Requirements
Acceptable Fuse Types and Current Rating for the Maxi, Mini, Micro Family of Converters
Package Size Input Voltage Output Voltage Output Power Required Fuse
Maxi (A) 72 3.3 264 Bussmann ABC-12
Maxi (A) 72 5, 8 300 Bussmann ABC-12
Maxi (A) 72 12, 15, 24, 28, 36, 48 400 Bussmann ABC-12
Mini (B) 72 3.3 100 Bussmann ABC-8
Mini (B) 72 5, 8 150 Bussmann ABC-8
Mini (B) 72 12, 15, 24, 28, 36, 48 250 Bussmann ABC-8
Micro (C) 72 3.3 75 Bussmann PC-Tron 5A
Micro (C) 72 5, 8 100 Bussmann PC-Tron 5A
Micro (C) 72 12, 15, 24, 28, 36, 48 150 Bussmann PC-Tron 5A
Maxi (A) 48 3.3 264 Bussmann ABC-10
Maxi (A) 48 5, 8 400 Bussmann ABC-15
Maxi (A) 48 12, 15, 24, 28, 36, 48 500 Bussmann ABC-20
Mini (B) 48 2 100 Bussmann ABC-8
Mini (B) 48 3.3 150 Bussmann ABC-8
Mini (B) 48 5, 8 200 Bussmann ABC-10
Mini (B) 48 12, 15, 24, 28, 36, 48 250 Bussmann ABC-10
Micro (C) 48 2 50 Bussmann PC-Tron 5A
Micro (C) 48 3.3 75 / 50 Bussmann PC-Tron 5A
Micro (C) 48 5, 8 100 / 75 / 50 Bussmann ABC-8
Micro (C) 48 12, 15, 24, 28, 36, 48 150 / 75 Bussmann ABC-8
Maxi (A) 28 3.3 150 Bussmann ABC-25
Maxi (A) 28 5 175 Bussmann ABC-25
Maxi (A) 28 6.5, 8, 12, 15, 24, 28, 36, 48 200 Bussmann ABC-30
Mini (B) 28 3.3 75 Bussmann ABC-15
Mini (B) 28 5 75 Bussmann ABC-15
Mini (B) 28 12, 15, 24, 28, 36, 48 150 Bussmann ABC-15
Micro (C) 28 3.3 50 Bussmann ABC- 8
Micro (C) 28 5 50 Bussmann ABC-10
Micro (C) 28 12, 15, 24, 28, 36, 48 100 Bussmann ABC-10
Maxi (A) 24 3.3 264 / 200 Bussmann ABC-25
Maxi (A) 24 5, 8, 12, 15, 24, 28, 36, 48 400 / 300 Bussmann ABC-30
Mini (B) 24 3.3 150 / 100 Bussmann ABC-15
Mini (B) 24 5, 8, 12, 15, 24, 28, 36, 48 200 / 150 Bussmann ABC-15
Micro (C) 24 3.3 75 / 50 Bussmann ABC-8
Micro (C) 24 5, 8, 12, 15, 24, 28, 36, 48 100 / 50 Bussmann ABC-10
