Current sharing in power arrays – Vicor Micro Family of DC-DC Converter User Manual
Page 25
Design Guide & Applications Manual
For Maxi, Mini, Micro Family DC-DC Converters and Configurable Power Supplies
Maxi, Mini, Micro Design Guide
Rev 4.9
vicorpower.com
Page 24 of 88
Apps. Eng. 800 927.9474
800 735.6200
5. Current Sharing In Power Arrays
+VIN
Parallel
Bus
T1
T2
-VIN
+VIN
+S
+OUT
SC
–S
–OUT
–IN
PR
PC
+IN
+S
+OUT
SC
–S
–OUT
–IN
PR
PC
+IN
Return
+VOUT
-VIN
DC-DC Converter
DC-DC Converter
Figure 5–3 — Transformer-coupled interface provides load sharing and SELV isolation from the primary source.
