10. High Boost HAM
90
80
70
60
50
40
O
PE
RA
TI
NG
T
EM
P
(D
EG
C
)
CURRENT (AMPS)
RATED CURRENT VS AMBIENT TEMPERATURE
1.0 2.0 3.0 4.0 5.0 6.0 7.0
Figure 10–12 — HAM filter’s current rating vs. temperature
90
80
70
60
50
40
30
20
10
0
DM
CM
0.01 0.04 0.1 0.4 1 4 10 40 100
0.02 0.07 0.2 0.7 2 7 20 70
FREQUENCY (MEGAHERTZ)
IN
SE
RT
IO
N
LO
SS
(d
b)
Figure 10–13 — HAM filter insertion loss vs. frequency
L).
REPRESENTS WORST
CASE LOCATION FOR
EDGE OF FILTER MKED 'A'
4 PL
6 PL
A
A
A
A
'0' '0'
'0'
'0'
FACE MAY BE
BOWED 0.04 MAX
NOTES
1. TOP OF INSERTS TO BE FLUSH TO .010
ABOVE TOP OF PLASTIC WASHER.
2. FILTER MUST HAVE VICOR AGENCY LABEL
(PART # 08094-01 CSA, TUV, U
4-40 INSERT
0.25 DP 4 PL
ø0.080 PIN
6 PLACES
L
O
A
D
L
IN
E
SEE
NOTE 1
RECOMMENDED CUSTOMER
MOUNTING
0.900 0.100
1.200
0.500 0.500
4.60 ±0.02
0.060
1.00
MAX
0.13 ±0.02
1.45
± 0.02
2.800
2.50
2.00
0.30 ±0.02
1.800
.102 ø TPH
ø.136
.060
.260
2.260
.3
1
0
4
.4
1
0
.100 2 PL
2.000 2 PL
1.900 2 PL
1.000 2 PL
.7
0
0
4
.0
0
0
2
P
L
3
.5
0
0
2
.5
0
0
2
P
L
1
.2
0
0
2
P
L
2.40±0.02
Figure 10–11 — HAM filter mechanical diagram
Table 10-2 — HAM filter part #30205 specifications
Parameter Min Typ Max Unit
Operating voltage 85 250 Vac
Operating temperature (See Fig.10-12) –20 50 °C
Leakage current at 264 Vac, 63 Hz
1.2 mA
(Either line to earth)
Operating current 6.3 A
Dielectric withstand (line – case) 1500 Vac
Residual voltage after 1 sec. 34 V
Operating frequency 50 60 Hz
Agency Approvals UL, CSA, TЬV
